Automatic feeding, pressing, button feeding, button sewing and material receiving with continuous operation without intervals; Pre-feeding function to save time; One person can operate 2-3 machines at the same time; No skill requirement for operation |  |  |
A series of processes for placket buttonholing takes 24 seconds. One person can operate 3 machines at the same time, with each machine taking only 8 seconds. Compared with ordinary universal machines, it achieves more than 7 times higher production efficiency.
Return on Investment: Calculated based on an average monthly salary of 4,500 yuan per person, the annual savings can reach 4,500 × 12 × 6 = 324,000 yuan; while increasing output, it reduces the skill requirements for operators, greatly saving costs.
Comparison of Process Time and Production Efficiency
| Process | Universal Machine | ZJ-USM8011 | |
| Marking 6 placket buttonhole positions*6 | 21s | 56s | 24 seconds per piece for one machine One person operates three machines simultaneously Average 8s |
| Placket buttonholing*6 | 35s | ||
| Production Volume | 514 pieces | 3,600 pieces | |
Working Time: 8 hours (28,800 seconds), Allowance Rate: 30%
Comparison of Introduction Effects
| Universal Machine | ZJ-USM8012 | Comparison of Introduction Effects | |
| Production Volume | 514 pieces | 5,760 pieces | 7 times |
| Process Time | 56s | 5s | 48s saved |
| Number of Workers | 4 Level C workers 3 Level D workers | 1 Level C worker | 6 workers reduced |
| Number of Equipment | 4 + 3 | 1 | 6 machines reduced |
| Number of Processes | 2 | 1 | 1 process reduced |
Note: Level A refers to skilled operators
Level B refers to operators who complete work under supervision
Level C refers to unskilled operators
Technical Parameters
| Machine Model | ZJ-UA-5781D-SY-WB5 |
| Equipped Head | ZJ5781DS-/3 |
| Maximum Sewing Speed | 4200sti/min |
| Button Length | ≤25 |
| Cutter Size | 6.4-19.1 (1/4-3/4) mm |
| Presser Foot Lifting Height | ≤14mm |
| Needle Used | DP×5 |
| Buttonhole Spacing | ≤610mm |
| Spacing Between Buttonhole and Fabric Edge | 7-21mm |
| Maximum Fabric Feeding Distance | ≤610mm |
| Upper Spacing | ≤140mm |
| Fabric Width | 220-420mm |
| Fabric Length | 480-880mm |
| Voltage | 220V |
| Air Pressure & Air Consumption | 0.5MPa 1.81/min |
| Machine Weight (Net Weight) | 353KG |
| Machine Weight (Gross Weight) | 483KG |
| Machine Dimensions (L×W×H) | 2300×1100×1500mm |
| Packaging Dimensions (L×W×H) | 2220×1070×1530mm |
UA: Woven fabric category SY: Buttonholing
